DC Signal Isolator Current Voltage Transmitter DIN Rail Mount 1?in 2?out 0?10V to 4?20mA GLG

31,90 €
+ 7,25 € Envío

DC Signal Isolator Current Voltage Transmitter DIN Rail Mount 1?in 2?out 0?10V to 4?20mA GLG

  • Marca: Unbranded
Vendido por:

DC Signal Isolator Current Voltage Transmitter DIN Rail Mount 1?in 2?out 0?10V to 4?20mA GLG

  • Marca: Unbranded

31,90 €

En existencias
+ 7,25 € Envío
Vendido por:

31,90 €

En existencias
+ 7,25 € Envío

Aceptamos los siguientes métodos de pago

Descripción

Item Type: DC Signal Isolator <br>Material: ABS <br>Model: GLG <br>Channel: 1 in 2 out <br>PWR (15-, 16+): 24V DC <br>Input: 0-10V <br>Distribution Voltage: DC24V <br>2-Wire System: (9-, 13+) <br>3-Wire System: (9+, 10-, 13+) <br>Power Supply: (9+,10-) <br>Output: <br>Channel 1 (1+, 2-): 4-20mA <br>Channel 2 (3+,4-): 4-20mA <br>Output Current: Load≤500Ω <br>Output Voltage: Load≥10KΩ <br>Accuracy: 0.1% FS <br>Working Temperature Range: -20~+55℃ <br>Electromagnetic Compatibility: Comply with GB/T 18268 (1EC61326-1) <br>Applicable Field Equipment: Two-wire, three-wire transmitter, current source<br>1、Come with three?proof paint spraying is used to protect circuit boards and related equipment from environmental erosion. Has good resistance to high and low temperature, excellent insulation, moisture resistance, leakage resistance, shock resistance, aging resistance, anti?corona, etc. <br>2、DC signal isolator allow 35mm standard rail installation, possess strong versatility <br>3、Provide input/output/power supply/shell isolation, so that have strong anti?interference ability and high reliability <br>4、The product provides isolated power distribution for the transmitter on site, and at the same time isolates and transmits the current signal generated by the transmitter from the site to the control room, PLC, DCS and other input terminal interface current source, two?wire system, three?wire system transmitter universal <br>5、Internal use of good?efficiency magnetic isolation technology, the input, output, and power supply are isolated from each other, with high accuracy, high linearity, low temperature drift, etc.1. The installation location must not have strong vibration, and the intensity of electromagnetic interference from the signal terminal, power terminal and space exceeding the third type of industrial field electromagnetic interference in the IEC61000?4 series. <br>2. There must be no harmful substances that cause severe corrosion to metal and plastic parts in the use environment.1 x DC Signal Isolator
  • Nº de Fruugo : 359857056-782642208
  • EAN: 6521278147364
